Revolution RGB 35W Animation Full Color Stage Laser Show System

Light source :

Diode with FAC (total 40W)
R: 12W/638nm
G: 12W/525nm
B: 16W/445nm

Diode brand :

R: Mitsubishi
G: Nichia
B: Nichia
(all Japanese brands)

Laser output :

35W

Divergence :

<1.0 mrad (full angle)

Modulation :

Analog

Laser class :

4

Scanner :

50kpps @ 8°, 60° max

Control :

ILDA in/out, DMX in/out, FB4 (optional)

Power supply:

AC90-240V, 50/60Hz

Power Cons. :

800W

Cooling :

TEC + Heatsink + Fans

IP grade :

IP54 dust-free

Working Tmp:

-20°C ~ 45°C

Dimension :

432 x 336 x 237mm (new)
(without hanging bracket)

Packing :

Flight case 62x62x54cm

Net weight :

24kg

Gross weight :

49kg
